Radial Insert Ball Bearing UK306 - Shaft: 25 mm

The massive bearing insert UK306 can be easily attached to the shaft with the help of an adapter sleeve or inserted in a housing. It is suitable for high radial loads. Main dimensions according to DIN 626-1.

Technical Data

Inside (mm):	25
Outside (mm):	72
Bore (mm):	30
Width (mm):	24
Tolerance for inside (mm):	0,021/0
Tolerance for outside (mm):	0/-0,013
Tolerance for width (mm):	0/-0,12
Rows Of Balls:	single row
Shaft Fastening:	Adapter Sleeve
Extended Inner Ring:	nein
Seal:	2-peace sealing system
Ring Material:	Rolling bearing steel
Rolling Element Material:	Rolling bearing steel
Cage Material:	Sheet Steel
Tolerance Class:	ABEC 1 / P0
Recommended tightening torque for housing attachment (Nm):	30
Magnetic:	yes
Product weight:	0,4360 kg

Item number: UK306

If your demand is large, please contact us for quotation and delivery time.

Delivery time:3 to 7 business day

$ 12.84

pcs

Technical Scribble

Technical Data

Inside (mm):	25
Outside (mm):	72
Bore (mm):	30
Width (mm):	24
Tolerance for inside (mm):	0,021/0
Tolerance for outside (mm):	0/-0,013
Tolerance for width (mm):	0/-0,12
Rows Of Balls:	single row
Shaft Fastening:	Adapter Sleeve
Extended Inner Ring:	nein
Seal:	2-peace sealing system
Ring Material:	Rolling bearing steel
Rolling Element Material:	Rolling bearing steel
Cage Material:	Sheet Steel
Tolerance Class:	ABEC 1 / P0
Recommended tightening torque for housing attachment (Nm):	30
Magnetic:	yes
Product weight:	0,4360 kg
