Rod End T.P.N.335 for Hydraulic Components - Requiring Maintenance 35x83x30 mm

The rod end T.P.N.335 for hydraulic components without seal requires maintenance and has a welding end. It has a sliding contact surface combination steel/steel and is suitable for heavy static loads as well as for shock loads. The main dimensions correspond to DIN 648 (DIN = German industrial norm).

Technical Data

Inside (mm):	35
Outside (mm):	83
Width (mm):	30
Tolerance for inside (mm):	0/-0,012
Tolerance for width (mm):	0/-0,12
Seal:	open
Ring Material:	Rolling bearing steel
Maintenance:	Requiring Maintenance
Tolerance Class:	ABEC 1 / P0
Mounting:	welding end rectangular
Sliding Contact Surface Combination:	steel/steel
Product weight:	1,5000 kg

Item number: T.P.N.335

If your demand is large, please contact us for quotation and delivery time.

Delivery time:3 to 7 business day

$ 21.42

pcs

Technical Scribble

Technical Data

Inside (mm):	35
Outside (mm):	83
Width (mm):	30
Tolerance for inside (mm):	0/-0,012
Tolerance for width (mm):	0/-0,12
Seal:	open
Ring Material:	Rolling bearing steel
Maintenance:	Requiring Maintenance
Tolerance Class:	ABEC 1 / P0
Mounting:	welding end rectangular
Sliding Contact Surface Combination:	steel/steel
Product weight:	1,5000 kg
