Plastic Flange Bearing / Flange Housing Unit SS UCFLPL209 W / TUCFL209 - Shaft: 45 mm

The flange bearing SS-UCFLPL209-W is suitable for high radial loads and for installation in various applications. It is hygienic and corrosion resistant with its plastic housing and stainless steel bearing insert.

Technical Data

Inside (mm):	45
Tolerance for inside (mm):	0,021/0
Shaft Fastening:	Grub Screws
Housing Type:	Flange
Grub Screw:	M8
Bearing No.:	SSUC 209
Housing No.:	FLPL 209
Ring Material:	Stainless Steel
Rolling Element Material:	Stainless Steel
Cage Material:	Stainless Steel
Housing Material:	Plastic
Tolerance Class:	ABEC 1 / P0
Number of Mounting Holes:	2
Housing Colour:	White
Tolerance for width Bi (mm):	0/-0,12
Product weight:	1,0000 kg

Item number: SS-UCFLPL209-W

If your demand is large, please contact us for quotation and delivery time.

Delivery time:3 to 7 business day

$ 55.35

pcs
