Deep Groove Ball Bearing 6809 ZZ / 2Z C3 / 61809 ZZ / 2Z C3 45x58x7 mm

Very narrow, very light and with extremely good spinning characteristics. The deep groove ball bearing 6809-ZZ / 2Z-C3 is very narrow and can also be used with limited space. The low weight allows for extremely high speeds.

Technical Data

Inside (mm):	45
Outside (mm):	58
Width (mm):	7
Tolerance for inside (mm):	0/-0,012
Tolerance for outside (mm):	0/-0,013
Tolerance for width (mm):	0/-0,12
Rows Of Balls:	single row
Seal:	ZZ
Internal Clearance:	C3 (increased clearance)
Flange:	no
Slot & Snap Ring:	no
Ring Material:	Rolling bearing steel
Rolling Element Material:	Rolling bearing steel
Cage Material:	Sheet Steel
Sealing material:	Sheet Steel
Full Complement Ball Set:	no
Tolerance Class:	ABEC 1 / P0
Type of lubrication:	greased
Magnetic:	yes
Lifetime lubricated:	yes
Product weight:	0,0400 kg

Item number: 6809-ZZ-C3

If your demand is large, please contact us for quotation and delivery time.

Delivery time:3 to 7 business day

$ 6.78
